View your world in more detail than ever with 4K HD recording for 4× the detail of 1080p. 4K video output lets you view live and recorded video in full resolution on a 4K TV. This NVR also supports Lorex Active Deterrence security cameras, which can stop potential events from happening thanks to their bright LED light and remote-triggered siren. Setup is quick and easy as well. The NVR's Power over Ethernet ports make setup quick and easy, with one cable installation per camera that provides both power and HD video.
LNK7000X Series
SPECIFICATIONS
8
CHANNELS
HD NVR supports up to 8 cameras
4K
RESOLUTION
Ultra high definition resolution
2-8TB
HARD DRIVE
Expandable up to 8TB
Lorex Cirrus Enabled
Experience the 4K difference
Don't miss a thing with this powerful 4K capable NVR. Record smooth 4K video in real-time (30 frames per second) on all 8 channels (8MP security cameras required). 4K resolution (3840 × 2160) compared to 1080p resolution (1920 × 1080) will provide you with a new level of detail and clarity. This higher pixel count also adds an increased ability to digitally zoom in on distant objects without significant image quality reduction. This means that 4K resolution will offer you the best chance to capture useful evidence such as distinct facial features if an incident occurs.
Compatible with select 4K Ultra HD Active Deterrence Security cameras
Add select Lorex 4K IP Active Deterrence security cameras to this NVR. Deterrence cameras include a super bright LED that can be customized to always be on, manually activated or triggered by motion, as well as a remote-triggered siren that is designed to stop trespassers right in their tracks.
Lorex Cirrus keeps you connected
Our free Lorex Cirrus™ app makes your surveillance system accessible from most mobile devices. With this app, you will be able to see exactly what your cameras see, at any time, review recorded footage, and keep track of all motion activity using easy-to-navigate timelines. You can also customize motion-activated push notifications to be sent directly to your phone or tablet's home screen so you can always be in the know
Lorex web client available
Lorex Client 13 gives you access to your security system and its settings over the Internet using a PC or Mac computer. With this software, you will be able to view live and recorded video, as well as save manual recordings and snapshots to your computer's hard drive. The software is available under the downloads section below.
Continuous, scheduled, and motion recording options
This NVR can record footage continuously, during scheduled times, or when movement is detected. These recording modes can be customized with each camera as well. A 5 second pre-recording function is also built-in for motion recordings. This means that you will never miss those first few vital moments of movement.
HEVC / H.265 video compression
This NVR is able to receive HEVC (High Efficiency Video Encoding) or H.265 video compression files. This type of encoding can save up to 40% more space when compared to H.264 Advanced Video Coding. Please note that IP security cameras with HEVC video compression are required to take advantage of this feature.
Rugged security-grade hard drive preinstalled
A security grade hard drive comes preinstalled within this NVR. This hard drive is designed for security systems, as it can work continuously without ever taking a break. You can also expand your total storage up to 16TB (2×8TB HDD).
Visit our to estimate your desired specifications.
Image resolution comparison
